It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residential buildings, barns, livestock sheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.
Supports OEM/ODM modifications to meet different working conditions and project needs.
Product Applications:
It is mainly used in situations where the working site is small, the ground is uneven, and the work content changes frequenty. It is suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residential buildings, barns, livestock sheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.
Features
· Compact and flexible,convenient for small terrain and narrow space operations.
· Simple and convenient operation,convenient transportation.
· Use thicker high-quality steel,apply plastic molding process,prevent rust and anti-corrosion.
· The 360-degree body rotates freely,and the smart body facilitates outdoor work.
| Model | T360 |
| Basic performance parameters | |
| Operating weight | 941kg |
| Bucket capacity | 0.1m³ |
| Climbing ability | 25° |
| Maximum breakout force | 3.5KN |
| Rated load | 200kg |
| Maximum load | 300kg |
| Travel speed | 0-6km/h |
| Vehicle width | 910mm |
| Rated pressure | 16Mpa |
| Bucket width | 1050mm |
| Max loading height | 1720mm |
| Max dumping height | 1386mm |
| Max operating height | 2400mm |
| Height to bucket pin | 1857mm |
| Max height bucket dump angle | 63° |
| Min height | 1300mm |
| Departure angle | 22° |
| Ground clearance | 173mm |
| Dumping distance | 250mm |
| Track contact length | 900mm |
| Dimensions | |
| Overall dimensions | 2092*1050*1300mm |
| Length including bucket | 2092mm |
| Length excluding bucket | 1726mm |
| Track model | 180*72*35 |
| Engine | |
| Brand | Lithium electricity/KOOP/Rato/B&S |
| Model | Lead-acid battery/192FH/R420D/XR13.5 |
| Rated power | 6kw,72V,125ah/7.6(7)/7.9/9.92kw |
| Cylinder | 1 |
| Intake method | Natural inhalation |
| Emission standard | EPA/ERUO5 |
| Fuel tank capacity | 5L |
We provide construction machinery, engineering equipment, pneumatic tools, and industrial machines suitable for global projects.
Yes, we offer OEM/ODM services, including modifications for working environment, machine structure, branding, and configuration.
All machines undergo strict inspection and operational testing. Core components are sourced from trusted suppliers to ensure durability and performance.
Yes, we have extensive export experience to over 100 countries, providing professional shipping, packaging, and documentation support.
We offer online technical guidance, maintenance assistance, spare parts supply, and troubleshooting support for global customers.
Our professional sales and technical teams ensure quick responses to inquiries, quotations, and technical questions.
